Waterproof Case Specifications

Complete specs for KeXinMaterials waterproof cases: IP67 / IP68, 12 sizes, 6 colors, marine-grade, 12h quote, 30-day delivery.

Available Models

Size	Model	Dimensions (L×W×H)	Weight	Wholesale Price (USD)
XS	WP-XS	190×130×75mm	0.3 kg	$19.90-29
S	WP-S	230×170×85mm	0.5 kg	$29-39
M	WP-M	330×230×110mm	0.9 kg	$39-59
L	WP-L	430×330×150mm	1.8 kg	$59-79
XL	WP-XL	530×400×200mm	3.2 kg	$79-99
XXL	WP-XXL	630×480×300mm	5.5 kg	$99-129
XXXL	WP-XXXL	800×600×400mm	9.0 kg	$129-149

Material Specifications

PP copolymer (impact + chemical resistance) + silicone O-ring + auto pressure valve + ABS latches + polypropylene hinge pin

Certifications

IP67 standard, IP68 optional, MIL-STD-810H drop, ISO 9001, CE, ROHS, FDA food-grade optional, ISTA 3A

Compatible Equipment

DSLR / mirrorless cameras, drones, smartphones, hard drives, documents, marine electronics, scientific instruments, medical supplies, emergency kits, hunting/fishing gear, two-way radios, GPS units, action cameras (GoPro / Insta360 / DJI Action)

Need a custom configuration?

Contact us for custom sizes, materials, colors, foam layouts, and OEM branding. 12h quote, 30-day delivery, MOQ 50-300pcs.

Email: kexin@beeaa.com WhatsApp: +86 13590555309

Pressure valve technology

Auto pressure equalization valves (GORE-TEX or similar) are critical for waterproof cases. They allow air pressure to equalize between the case interior and exterior when subjected to altitude or temperature changes. Without a pressure valve, the case can become vacuum-sealed (hard to open) or burst seal at altitude. Pressure valves also reduce condensation by allowing humid air to escape before sealing. KeXinMaterials uses GORE-TEX PM100 valves rated for 1.5 psi pressure differential.

Saltwater testing

For marine applications, we test cases in 5% NaCl solution (simulating seawater) for 1,000 hours. Pass criteria: no visible corrosion, no seal degradation, no foam water absorption. This is more demanding than standard IP testing and ensures our marine cases last 5+ years in saltwater service.
